Huawei quidway s7700 - Configuring Multicast VLAN Replication Based on User Vlans

Pre-configuration Tasks
Before configuring multicast VLAN replication based on user VLANs, complete the following
tasks:
l Connecting interfaces and setting physical parameters for the interfaces to ensure that the
physical status of the interfaces is Up
l Enabling IGMP snooping globally
Data Preparation
To configure multicast VLAN replication based on user VLANs, you need the following data.
No. Data
1 Multicast VLAN ID
2 User VLAN IDs
3 Types and numbers of interfaces
3.3.2 Configuring Multicast VLAN Replication Based on User
VLANs
Procedure
Step 1 Run:
system-view
The system view is displayed.
Step 2 Run:
vlan vlan-id
A VLAN is created and the VLAN view is displayed.
Step 3 Run:
igmp-snooping enable
IGMP snooping is enabled in the VLAN.
Step 4 Run:
multicast-vlan enable
Multicast VLAN replication is enabled, and the VLAN is configured as a multicast VLAN.
By default, multicast VLAN replication is disabled.
After IP multicast is configured on the S7700, no multicast VLAN can be configured.
Step 5 Run:
multicast-vlan user-vlan { { vlan-id1 [ to vlan-id2 ] } & <1-10> }
User VLANs are bound to the multicast VLAN.
