Huawei quidway s7700 - Configuring Multicast VLAN Replication Based on Interfaces; Establishing the Configuration Task

<Quidway> display multicast-vlan vlan 3
Multicast-vlan : 3
User-vlan Number : 2
IGMP snooping state : Enable
MLD snooping state : Disable
User-vlan Snooping-state
-----------------------------------------------
100 IGMP Enable /MLD Disable
200 IGMP Enable /MLD Disable
Run the display user-vlan vlan [ vlan-id ] command to view information about user VLANs.
<Quidway> display user-vlan vlan
Total user vlan 2
user-vlan snooping-state multicast-vlan snooping-state
---------------------------------------------------------
100 IGMP Enable /MLD Disable 3 IGMP Enable /MLD Disable
200 IGMP Enable /MLD Disable 3 IGMP Enable /MLD Disable
3.4 Configuring Multicast VLAN Replication Based on
Interfaces
This section describes how to configure multicast VLAN replication based on interfaces.
3.4.1 Establishing the Configuration Task
Applicable Environment
A carrier provides the multicast service for multiple Internet service providers (ISPs) and assigns
a multicast VLAN to each ISP to isolate multicast data and routes. The ISPs provide multicast
services for users on different interfaces. The interfaces may be added to the same user VLAN,
so multicast packets of an ISP may be sent to users that do not subscribe to services of this ISP.
To protect interests of ISPs, the carrier can bind user VLANs to multicast VLANs on the user-
side interfaces. Multicast data packets of a user VLAN are then sent to the specified interface.
Pre-configuration Tasks
Before configuring multicast VLAN replication based on interfaces, complete the following
tasks:
l Connecting interfaces and setting physical parameters for the interfaces to ensure that the
physical status of the interfaces is Up
l Enabling IGMP snooping globally
Data Preparation
To configure multicast VLAN replication based on interfaces, you need the following data.
No.
Data
1 Multicast VLAN ID
2 User VLAN IDs
Quidway S7700 Smart Routing Switch
Configuration Guide - Multicast 3 Multicast VLAN Replication Configuration
Issue 01 (2011-07-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
59
