10
MENU SCREEN OPERATION
10-12
■ DUP/TONE items
Offset frequency (Default: 5.000.00*)
DUP/TONE... > Offset Freq(OFFSET FREQ)
Sets the offset frequency for duplex (repeater) operation to between 0 and
59.99500 MHz.
• The selected tuning step in the VFO mode is used when setting the offset
frequency.
• Push [V/MHz]
to select 1 MHz or 10 MHz steps.
• The duplex shift direction (DUP-/DUP+) is set in the Quick Menu screen.
(p. 1-5)
*The default setting is differ, depending on the version.
Repeater Tone (Default: 88.5)
DUP/TONE... > Repeater Tone(REPEATER TONE)
Selects subaudible tone frequencies, for repeater access and other func-
tions. 50 tone frequencies (67.0–254.1 Hz) are selectable.
TSQL Freq (Default: 88.5)
DUP/TONE... > TSQL Freq(TSQL TONE)
Selects the tone frequency for the tone squelch or pocket beep. 50 fre-
quencies (67.0–254.1 Hz) are selectable.
• Available repeater tone/tone squelch frequencies
(Unit: Hz)
67.0
69.3
71.9
74.4
77.0
79.7
82.5
085.4
088.5
091.5
094.8
097.4
100.0
103.5
107.2
110.9
114.8
118.8
123.0
127.3
131.8
136.5
141.3
146.2
151.4
156.7
159.8
162.2
165.5
167.9
171.3
173.8
177.3
179.9
183.5
186.2
189.9
192.8
196.6
199.5
203.5
206.5
210.7
218.1
225.7
229.1
233.6
241.8
250.3
254.1
The transceiver has 50 tone frequencies and consequently their spacing
is narrow compared with units having 38 tones. Therefore, some tone
frequencies may receive interference from adjacent tone frequencies.
