50 User’s Manual INNOMAR Parametric Sub-Bottom Profilers / SESWIN
50 Innomar Technologie GmbH (2023-01)
long range shallow water,
Standard Sync Mode
shallow water,
Multiple Detection
water surface
direct seabed
return
first multiple
return
second multiple
return
Area / Profile Counter
To annotate the recorded data, it is possible to set an area name
and a profile number. The area name can also be used as data file
name prefix. The profile number can be set to be increased
automatically at each record start, see below.
!
Changes will not take effect before the “Apply” button is pressed. To remind on
changes not active yet, the tick mark is highlighted if anything has changed. Please
note the length for the area name string is limited to 20 characters.
General Settings
In this dialog, some more annotation can be set that
will be stored with the recorded data:
 ship’s name and
 travel ID
This information will be stored with the recorded data
and might be useful for data handling.
There is a checkbox to enable an automatic increment
of the profile number with each record start.
!
Please note the length for the annotation strings (ship name, travel ID, area name)
is limited to 20 characters.
