Host-PCI Express* Graphics Bridge Registers (D1:F0)
R
120 Intel
®
82925X/82925XE MCH Datasheet
8.1.14 SSTS1—Secondary Status (D1:F0)
PCI Device: 1
Address Offset: 1Eh
Default Value: 00h
Access: RO, R/W/C
Size: 16 bits
SSTS1 is a 16-bit status register that reports the occurrence of error conditions associated with
secondary side (i.e., PCI Express Graphics side) of the “virtual” PCI-PCI Bridge in the MCH.
Bit Access &
Default
Description
15 R/WC
0b
Detected Parity Error (DPE):
1 = The MCH received across the link (upstream) a Posted Write Data Poisoned
TLP (EP=1).
14 R/WC
0b
Received System Error (RSE):
1 = Secondary side sends an ERR_FATAL or ERR_NONFATAL message due to
an error detected by the secondary side, and the SERR Enable bit in the
Bridge Control register is 1.
13 R/WC
0b
Received Master Abort (RMA):
1 = Secondary Side for Type 1 Configuration Space Header Device (for requests
initiated by the Type 1 Header Device itself) receives a completion with
Unsupported Request Completion Status.
12 R/WC
0b
Received Target Abort (RTA):
1 = Secondary Side for Type 1 Configuration Space Header Device (for requests
initiated by the Type 1 Header Device itself) receives a completion with
Completer Abort Completion Status.
11 RO
0b
Signaled Target Abort (STA): Hardwired to 0. The MCH does not generate
Target Aborts (the MCH will never complete a request using the Completer Abort
Completion status).
10:9 RO
00b
DEVSELB Timing (DEVT): Hardwired to 0.
8 R/WC
0b
Master Data Parity Error (SMDPE):
1 = The MCH received across the link (upstream) a Read Data Completion
Poisoned TLP (EP=1).
Note: This bit can only be set when the Parity Error Enable bit in the Bridge
Control register is set.
7 RO
0b
Fast Back-to-Back (FB2B): Hardwired to 0.
6 Reserved
5 RO
0b
66/60 MHz capability (CAP66): Hardwired to 0.
4:0 Reserved
