MCHBAR Registers

Intel

82925X/82925XE MCH Datasheet 85

5.1.8 C0BNKARC—Channel A DRAM Bank Architecture

MMIO Range: MCHBAR

Address Offset: 10Eh

Default Value: 0000h

Access: R/W

Size: 16 bits

This register is used to program the bank architecture for each Rank.

Bit Access &

Default

Description

15:8 Reserved

7:6 R/W

00b

Rank 3 Bank Architecture

00 = 4 Bank.

01 = 8 Bank.

1X = Reserved

5:4 R/W

00b

Rank 2 Bank Architecture

00 = 4 Bank.

01 = 8 Bank.

1X = Reserved

3:2 R/W

00b

Rank 1 Bank Architecture

00 = 4 Bank.

01 = 8 Bank.

1X = Reserved

1:0 R/W

00b

Rank 0 Bank Architecture

00 = 4 Bank.

01 = 8 Bank.

1X = Reserved
