Testability
R
Intel
®
82925X/82925XE MCH Datasheet 223
Table 13-3. XOR Chain #0
Chain Pin Count Ball Number Signal Name
0 1 M14 ICH_SYNC#
0 2 K16 EXTTS#
0 3 G24 HCPURST#
0 4 K17 HD44
0 5 M18 HD42
0 6 K18 HD43
0 7 F17 HD47
0 8 M19 HD38
0 9 K21 HD39
0 10 K19 HDINV2#
0 11 H18 HD46
0 12 J19 HDSTBP2#
0 13 F19 HDSTBN2#
0 14 G18 HD45
0 15 K22 HD34
0 16 M21 HD36
0 17 J21 HD35
0 18 H20 HD40
0 19 H19 HD41
0 20 J24 HD33
0 21 J22 HD32
0 22 H23 HD37
0 23 A25 HD48
0 24 A29 HD55
0 25 D27 HD60
0 26 B26 HDINV3#
0 27 B29 HDSTBP3#
0 28 C29 HDSTBN3#
0 29 C25 HD58
0 30 B30 HD51
0 31 E27 HD24
0 32 C30 HD17
0 33 E25 HD25
