Page #161 background image
System Address Map
R
Intel
®
82925X/82925XE MCH Datasheet 161
9.1.4 Extended System BIOS Area (E_0000h–E_FFFFh)
This 64-KB area (000E_0000h–000E_FFFFh) is divided into four, 16-KB segments. Each
segment can be assigned independent read and write attributes so it can be mapped either to main
DRAM or to the DMI. Typically, this area is used for RAM or ROM. Memory segments that are
disabled are not remapped elsewhere.
Non-snooped accesses from PCI Express or DMI to this region are always sent to main memory.
Table 9-2. Extended System BIOS Area Memory Segments
Memory Segments Attributes Comments
0E0000h–0E3FFFh W/R BIOS Extension
0E4000h–0E7FFFh W/R BIOS Extension
0E8000h–0EBFFFh W/R BIOS Extension
0EC000h–0EFFFFh W/R BIOS Extension
9.1.5 System BIOS Area (F_0000h–F_FFFFh)
This area is a single, 64-KB segment (000F_0000h – 000F_FFFFh). This segment can be
assigned read and write attributes. It is by default (after reset) read/write disabled and cycles are
forwarded to the DMI. By programming the read/write attributes, the MCH can “shadow” BIOS
into main memory. When disabled, this segment is not remapped.
Non-snooped accesses from PCI Express or DMI to this region are always sent to main memory.
Table 9-3. System BIOS Area Memory Segments
Memory Segments Attributes Comments
0F0000h–0FFFFFh WE RE BIOS Area
9.1.6 Programmable Attribute Map (PAM) Memory Area Details
The 13 sections from 768 KB to 1 MB comprise what is also known as the PAM memory area.
The MCH does not handle IWB (Implicit Write-Back) cycles targeting DMI. Since all memory
residing on DMI should be set as non-cacheable, there will normally not be IWB cycles targeting
DMI.
However, DMI becomes the default target for processor and DMI originated accesses to disabled
segments of the PAM region. If the MTRRs covering the PAM regions are set to WB or RC, it is
possible to get IWB cycles targeting DMI. This may occur for DMI-originated cycles to disabled
PAM regions.
Note: For example, assume that a particular PAM region is set for “Read Disabled” and the MTRR
associated with this region is set to WB. A DMI master generates a memory read targeting the
PAM region. A snoop is generated on the FSB and the result is an IWB. Since the PAM region is
“Read Disabled”, the default target for the memory read becomes DMI. The IWB associated with
this cycle will cause the MCH to hang.
