Ballout and Package Information
R
196 Intel
®
82925X/82925XE MCH Datasheet
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
BSEL0 H16
BSEL1 E15
BSEL2 D17
DMI_RXN0 U6
DMI_RXN1 T8
DMI_RXN2 V8
DMI_RXN3 U10
DMI_RXP0 U5
DMI_RXP1 T9
DMI_RXP2 V7
DMI_RXP3 V10
DMI_TXN0 T3
DMI_TXN1 U1
DMI_TXN2 V3
DMI_TXN3 W5
DMI_TXP0 R3
DMI_TXP1 T1
DMI_TXP2 U3
DMI_TXP3 V5
DREFCLKN M12
DREFCLKP M13
EXP_COMPI W10
EXP_COMPO Y10
EXP_RXN0 F11
EXP_RXN1 H11
EXP_RXN10 L5
EXP_RXN11 R10
EXP_RXN12 M7
EXP_RXN13 N5
EXP_RXN14 P8
EXP_RXN15 R5
EXP_RXN2 E9
EXP_RXN3 E7
EXP_RXN4 B4
EXP_RXN5 E5
EXP_RXN6 G5
EXP_RXN7 H7
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
EXP_RXN8 J5
EXP_RXN9 K7
EXP_RXP0 E11
EXP_RXP1 J11
EXP_RXP10 L6
EXP_RXP11 P10
EXP_RXP12 M8
EXP_RXP13 N6
EXP_RXP14 P7
EXP_RXP15 R6
EXP_RXP2 F9
EXP_RXP3 F7
EXP_RXP4 B3
EXP_RXP5 D5
EXP_RXP6 G6
EXP_RXP7 H8
EXP_RXP8 J6
EXP_RXP9 K8
EXP_TXN0 C9
EXP_TXN1 A8
EXP_TXN10 K3
EXP_TXN11 L1
EXP_TXN12 M3
EXP_TXN13 N1
EXP_TXN14 P3
EXP_TXN15 R1
EXP_TXN2 C7
EXP_TXN3 A6
EXP_TXN4 C5
EXP_TXN5 D2
EXP_TXN6 F3
EXP_TXN7 G1
EXP_TXN8 H3
EXP_TXN9 J1
EXP_TXP0 C10
EXP_TXP1 A9
EXP_TXP10 J3
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
EXP_TXP11 K1
EXP_TXP12 L3
EXP_TXP13 M1
EXP_TXP14 N3
EXP_TXP15 P1
EXP_TXP2 C8
EXP_TXP3 A7
EXP_TXP4 C6
EXP_TXP5 C2
EXP_TXP6 E3
EXP_TXP7 F1
EXP_TXP8 G3
EXP_TXP9 H1
EXTTS# K16
GCLKN B11
GCLKP A11
HA3# H29
HA4# K29
HA5# J29
HA6# G30
HA7# G32
HA8# K30
HA9# L29
HA10# M30
HA11# L31
HA12# L28
HA13# J28
HA14# K27
HA15# K33
HA16# M28
HA17# R29
HA18# L26
HA19# N26
HA20# M26
HA21# N31
HA22# P26
HA23# N29
