Ballout and Package Information
R
Intel
®
82925X/82925XE MCH Datasheet 207
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
A1 —
A2 NC
A3 VSS
A4 —
A5 VSS
A6 EXP_TXN3
A7 EXP_TXP3
A8 EXP_TXN1
A9 EXP_TXP1
A10 VSS
A11 GCLKP
A12 VCCA_DPLLA
A13 VCC2
A14 VCCA_EXPPLL
A15 RSV
A16 RSV
A17 VCCA_HPLL
A18 VSS
A19 VTT
A20 VTT
A21 VTT
A22 VTT
A23 HSWING
A24 HVREF
A25 HD48
A26 VSS
A27 HD61
A28 HD57
A29 HD55
A30 VSS
A31 HD53
A32 —
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
A33 VSS
A34 NC
A35 NC
B1 NC
B2 VSS
B3 EXP_RXP4
B4 EXP_RXN4
B5 VSS
B6 VSS
B7 VSS
B8 VSS
B9 VSS
B10 VSS
B11 GCLKN
B12 VSS
B13 VCCA_DPLLB
B14 VSS
B15 RSV
B16 VSS
B17 VCCA_SMPLL
B18 VSS
B19 VTT
B20 VTT
B21 VTT
B22 VTT
B23 HRCOMP
B24 VSS
B25 HD63
B26 HDINV3#
B27 HD54
B28 VSS
B29 HDSTBP3#
B30 HD51
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
B31 HD52
B32 HD15
B33 HD13
B34 HD11
B35 NC
C1 VSS
C2 EXP_TXP5
C3 VSS
C4 VSS
C5 EXP_TXN4
C6 EXP_TXP4
C7 EXP_TXN2
C8 EXP_TXP2
C9 EXP_TXN0
C10 EXP_TXP0
C11 VSS
C12 —
C13 VSS
C14 RSV
C15 MTYPE
C16 NC
C17 VSS
C18 VSS
C19 VTT
C20 VTT
C21 VTT
C22 VTT
C23 VSS
C24 —
C25 HD58
C26 HD59
C27 HD49
C28 HD56
