Host Bridge/DRAM Controller Registers (D0:F0)
R
Intel
®
82925X/82925XE MCH Datasheet 77
4.1.36 CAPID0—Capability Identifier (D0:F0)
PCI Device: 0
Address Offset: E0h
Default Value: 000000000001090009h
Access: RO
Size: 72 bits
Bit Access &
Default
Description
71:28 Reserved
27:24 RO
1h
CAPID Version: This field has the value 0001b to identify the first revision of the
CAPID register definition.
23:16 RO
09h
CAPID Length: This field has the value 09h to indicate the structure length
(9 bytes).
15:8 RO
00h
Next Capability Pointer: This field is hardwired to 00h indicating the end of the
capabilities linked list.
7:0 RO
09h
CAP_ID: This field has the value 1001b to identify the CAP_ID assigned by the
PCI SIG for vendor dependent capability pointers.
§
