Host Bridge/DRAM Controller Registers (D0:F0)
R
Intel
®
82925X/82925XE MCH Datasheet 63
4.1.21 PAM1—Programmable Attribute Map 1 (D0:F0)
PCI Device: 0
Address Offset: 91h
Default Value: 00h
Access: R/W
Size: 8 bits
This register controls the read, write, and shadowing attributes of the BIOS areas from 0C0000h–
0C7FFFh.
Bit Access &
Default
Description
7:6 Reserved
5:4 R/W
00b
0C4000-0C7FFF Attribute (HIENABLE): This field controls the steering of read and
write cycles that address the BIOS area from 0C4000h to 0C7FFFh.
00 = DRAM Disabled: Accesses are directed to the DMI.
01 = Read Only: All reads are serviced by DRAM. All writes are forwarded to the
DMI.
10 = Write Only: All writes are sent to DRAM. Reads are serviced by DMI.
11 = Normal DRAM Operation: All reads and writes are serviced by DRAM.
3:2 Reserved
1:0 R/W
00b
0C0000-0C3FFF Attribute (LOENABLE): This field controls the steering of read
and write cycles that address the BIOS area from 0C0000h to 0C3FFFh.
00 = DRAM Disabled: Accesses are directed to the DMI.
01 = Read Only: All reads are serviced by DRAM. All writes are forwarded to the
DMI.
10 = Write Only: All writes are sent to DRAM. Reads are serviced by DMI.
11 = Normal DRAM Operation: All reads and writes are serviced by DRAM.
