Functional Description
R
178 Intel
®
82925X/82925XE MCH Datasheet
10.3.1.2 System Memory Supported Configurations
The MCH supports the 256-Mbit, 512-Mbit and 1-Gbit technology-based DIMMs from
Table 10-3.
Table 10-3. DDR2 DIMM Supported Configurations
Technology Configuration # of
Row
Address
Bits
# of Column
Address Bits
# of Bank
Address
Bits
Page
Size
Rank
Size
256 Mbit 16M X 16 13 9 2 4K 128 MB
256 Mbit 32M X 8 13 10 2 8K 256 MB
512 Mbit 32M X 16 13 10 2 8K 256 MB
512 Mbit 64M X 8 13 11 2 16K 512 MB
512 Mbit 64M X 8 14 10 2 8K 512 MB
1 Gbit 64M X 16 14 10 2 8K 512 MB
1 Gbit 128M X 8 14 11 2 16K 1 GB
1 Gbit 64M X 16 13 10 3 8K 512 MB
1 Gbit 128M X 8 14 10 3 8K 1 GB
10.3.1.3 Main Memory DRAM Address Translation and Decoding
Table 10-4 and Table 10-5 specify the host interface to memory interface address multiplex for
the MCH. Refer to the details of the various DIMM configurations as described in Table 10-3.
The address lines specified in the column header refer to the host (processor) address lines.
