MCHBAR Registers
R
92 Intel
®
82925X/82925XE MCH Datasheet
5.1.21 PMCFG—Power Management Configuration
MMIO Range: MCHBAR
Address Offset: F10h
Default Value: 00000000h
Access: R/W
Size: 32 bits
Bit Access &
Default
Description
31:5 Reserved
4 R/W
0b
Enhanced Power Management Features Enable
0 = Legacy power management mode
1 = Reserved.
3:0 Reserved
5.1.22 PMSTS—Power Management Status
MMIO Range: MCHBAR
Address Offset: F14h
Default Value: 00000000h
Access: R/W
Size: 32 bits
This register is Reset by PWROK only.
Bit Access &
Default
Description
31:2 Reserved
1 R/WC/S
0b
Channel B in self-refresh. This bit is set by power management hardware after
Channel B is placed in self refresh as a result of a Power State or a Reset Warn
sequence. It is cleared by power management hardware before starting Channel
B self refresh exit sequence initiated by a power management exit. It is cleared
by BIOS in a warm reset (Reset# asserted while pwrok is asserted) exit
sequence.
0 = Channel B not guaranteed to be in self-refresh.
1 = Channel B in Self-Refresh.
0 R/WC/S
0b
Channel A in Self-refresh. Set by power management hardware after Channel
A is placed in self refresh as a result of a Power State or a Reset Warn
sequence. It is cleared by power management hardware before starting Channel
A self refresh exit sequence initiated by a power management exit. It is cleared
by the BIOS in a warm reset (Reset# asserted while PWOK is asserted) exit
sequence.
0 = Channel A not guaranteed to be in self-refresh.
1 = Channel A in Self-Refresh.
§
