5.1.5 C0DRA0—Channel A DRAM Rank 0,1 Attribute
MMIO Range: MCHBAR
Address Offset: 108h
Default Value: 00h
Access: R/W
Size: 8 bits
The DRAM Rank Attribute Registers define the page sizes to be used when accessing different
ranks. These registers should be left with their default value (all zeros) for any rank that is
unpopulated, as determined by the corresponding CxDRB registers. Each byte of information in
the CxDRA registers describes the page size of a pair of ranks.
Channel and Rank Map:
Channel A Rank 0, 1: 108h
Channel A Rank 2, 3: 109h
Channel B Rank 0, 1: 188h
Channel B Rank 2, 3: 189h
Bit Access &
Default
Description
7 Reserved
6:4 R/W
000b
Channel A DRAM odd Rank Attribute: This 3 bit field defines the page size of
the corresponding rank.
000 = Unpopulated
001 = Reserved
010 = 4 KB
011 = 8 KB
100 = 16 KB
Others = Reserved
3 Reserved
2:0 R/W
000b
Channel A DRAM even Rank Attribute: This 3 bit field defines the page size of
the corresponding rank.
000 = Unpopulated
001 = Reserved
010 = 4 KB
011 = 8 KB
100 = 16 KB
Others = Reserved
5.1.6 C0DRA2—Channel A DRAM Rank 2,3 Attribute
MMIO Range: MCHBAR
Address Offset: 109h
Default Value: 00h
Access: R/W
Size: 8 bits
The operation of this register is detailed in the description for register C0DRA0.
