Host Bridge/DRAM Controller Registers (D0:F0)
R
Intel
®
82925X/82925XE MCH Datasheet 57
4.1.15 DMIBAR—Root Complex Register Range Base Address
(D0:F0)
PCI Device: 0
Address Offset: 4Ch
Default Value: 00000000h
Access: R/W
Size: 32 bits
This is the base address for the Root Complex configuration space. This window of addresses
contains the Root Complex Register set for the PCI Express hierarchy associated with the MCH.
There is no physical memory within this 4-KB window that can be addressed. The
4 KB that is reserved by this register does not alias to any PCI 2.3 compliant memory mapped
space.
On reset, this register is disabled and must be enabled by writing a 1 to the DMIBAREN [Dev 0,
offset 54h, bit 29].
|
Bit Access &
Default
Description
31:12 R/W
0000 0h
DMI Base Address: This field corresponds to bits 31 to 12 of the base address
DMI configuration space.
BIOS will program this register resulting in a base address for a 4-KB block of
contiguous memory address space. This register ensures that a naturally
aligned 4-KB space is allocated within total addressable memory space of
4 GB.
System software uses this base address to program the DMI register set.
11:0 Reserved
