Host-PCI Express* Graphics Bridge Registers (D1:F0)
R
Intel
®
82925X/82925XE MCH Datasheet 139
8.1.37 LCTL—Link Control (D1:F0)
PCI Device: 1
Address Offset: B0h
Default Value: 0000h
Access: RO, R/W
Size: 16 bits
This register allows control of PCI Express link.
Bit Access &
Default
Description
15:8 Reserved
7 Reserved. Must be 0 when writing this register.
6 R/W
0b
Common Clock Configuration
0 = This component and the component at the opposite end of this Link are
operating with asynchronous reference clock.
1 = This component and the component at the opposite end of this Link are
operating with a distributed common reference clock.
Components use this common clock configuration information to report the correct
L0s and L1 Exit Latencies.
5 R/W
0b
Retrain Link
0 = Normal operation
1 = Full Link retraining is initiated by directing the Physical Layer LTSSM from L0,
L0s, or L1 states to the Recovery state.
This bit always returns 0 when read. This bit is cleared automatically (no need to
write a 0).
4 R/W
0b
Link Disable
0 = Normal operation
1 = Link is disabled. Forces the LTSSM to transition to the Disabled state (via
Recovery) from L0, L0s, or L1 states.
Link retraining happens automatically on 0 to 0 transition, just like when coming
out of reset. Writes to this bit are immediately reflected in the value read from the
bit, regardless of actual Link state.
3 RO
0b
Read Completion Boundary (RCB): Hardwired to 0 to indicate 64 byte.
2 Reserved
1:0 R/W
00b
Active State PM: This field controls the level of active state power management
supported on the given link.
00 = Disabled
01 = L0s Entry Supported
10 = Reserved
11 = L0s and L1 Entry Supported
