Host Bridge/DRAM Controller Registers (D0:F0)
R
Intel
®
82925X/82925XE MCH Datasheet 61
4.1.19 DERRDST—DRAM Error Destination (D0:F0) (Intel
®
82925X
Only)
PCI Device: 0
Address Offset: 5Dh
Default Value: 00h
Access: RO/S
Size: 8 bits
This register is used to report the destination of the data containing an ECC error whose address is
recorded in DEAP register.
Bit Access &
Default
Description
7:6 Reserved
5:0 RO/S
00h
Error Source Code: This field is updated concurrently with DERRSYN.
00h = Processor to memory reads
01h–07h = Reserved
08h–09h = DMI VC0 initiated and targeting cycles/data
0Ah–0Bh = DMI VC1 initiated and targeting cycles/data
0Ch–0Dh = DMI VCp initiated and targeting cycles/data
0Eh–0Fh = Reserved
10h = PCI Express* initiated and targeting cycles/data
11h = Reserved
12h = PCI Express* initiated and targeting cycles/data
13h = Reserved
14h–16h = PCI Express* initiated and targeting cycles/data
17h = Reserved
18h–1Ah: = Reserved
1Bh–3Eh = Reserved
3Fh = Used for broadcast messages with data targeting multiple units. (e.g.,
EOI). These bits are reset on PWROK.
