Testability
R
Intel
®
82925X/82925XE MCH Datasheet 235
Table 13-9. XOR Chain #6
Chain Pin Count Ball Number Signal Name
6 1 AG17 SDQS_A3#
6 2 AF17 SDM_A3
6 3 AJ17 SDQ_A31
6 4 AK16 SDQ_A30
6 5 AE15 SDQ_A28
6 6 AN19 SCKE_A1
6 7 AP21 SMA_A11
6 8 AP22 SMA_A9
6 9 AN22 SMA_A5
6 10 AR20 SBS_A2
6 11 AN21 SMA_A7
6 12 AN20 SMA_A12
6 13 AP19 SCKE_A0
6 14 AR19 SCKE_A3
6 15 AP7 SDQS_A2
6 16 AM9 SDQ_A18
6 17 AL7 SDQ_A19
6 18 AM8 SDQ_A23
6 19 AM7 SDQ_A22
6 20 AP6 SDM_A2
6 21 AK7 SDQ_A17
6 22 AP5 SDQ_A16
6 23 AN5 SDQ_A21
6 24 AR5 SDQ_A20
6 25 AM2 SCLK_A4#
6 26 AM3 SCLK_A4
6 27 AN2 SCLK_A1
6 28 AP4 SDQ_A11
6 29 AP3 SDQ_A15
6 30 AP2 SDQ_A14
6 31 AN4 SDQ_A10
6 32 AK3 SDQ_A9
6 33 AK2 SDQ_A8
