System Address Map
R
160 Intel
®
82925X/82925XE MCH Datasheet
Compatible SMRAM Address Range (A_0000h–B_FFFFh)
When compatible SMM space is enabled, SMM-mode processor accesses to this range are routed
to physical system DRAM at 000A_0000h–000B_FFFFh. Non-SMM-mode processor accesses to
this range are considered to be to the Video Buffer Area as described above. PCI Express and
DMI originated cycles to enabled SMM space are not allowed. PCI Express and DMI initiated
cycles are attempted as peer cycles, and will master abort on PCI if no external VGA device
claims them.
Monochrome Adapter (MDA) Range (B_0000h–B_7FFFh)
Legacy support requires the ability to have a second graphics controller (monochrome) in the
system. Accesses in the standard VGA range are forwarded to PCI Express or the DMI
(depending on the programming of the on-chip registers). Since the monochrome adapter may be
mapped to any one of these devices, the MCH must decode cycles in the MDA range
(000B_0000h – 000B_7FFFh) and forward either PCI Express or the DMI. In addition to the
memory range B0000h to B7FFFh, the MCH decodes I/O cycles at 3B4h, 3B5h, 3B8h, 3B9h,
3BAh and 3BFh and forwards them to the either PCI Express, and/or the DMI.
9.1.3 Expansion Area (C_0000h–D_FFFFh)
This 128-KB ISA Expansion region (000C_0000h – 000D_FFFFh) is divided into eight, 16-KB
segments. Each segment can be assigned one of four read/write states: read only, write only,
read/write, or disabled. Typically, these blocks are mapped through the MCH and are
subtractively decoded to ISA space. Memory that is disabled is not remapped.
Non-snooped accesses from PCI Express or DMI to this region are always sent to main memory.
Table 9-1. Expansion Area Memory Segments
Memory Segments Attributes Comments
0C0000h–0C3FFFh W/R Add-on BIOS
0C4000h–0C7FFFh W/R Add-on BIOS
0C8000h–0CBFFFh W/R Add-on BIOS
0CC000h –0CFFFFh W/R Add-on BIOS
0D0000h–0D3FFFh W/R Add-on BIOS
0D4000h–0D7FFFh W/R Add-on BIOS
0D8000h–0DBFFFh W/R Add-on BIOS
0DC000h–0DFFFFh W/R Add-on BIOS
