9.2.2 TSEG
TSEG is optionally 1 MB, 2 MB, or 8 MB in size. SMM-mode processor accesses to enabled
TSEG access the physical DRAM at the same address. Non-processor originated accesses are not
allowed to SMM space. PCI Express and DMI originated cycles to enabled SMM space are
handled as invalid cycle type with reads and writes to location 0 and byte enables turned off for
writes. When the extended SMRAM space is enabled, processor accesses to the TSEG range
without SMM attribute or without WB attribute are also forwarded to memory as invalid accesses.
Non-SMM-mode write-back cycles that target TSEG space are completed to main memory for
cache coherency. When SMM is enabled, the maximum amount of memory available to the
system is equal to the amount of physical main memory minus the value in the TSEG register
which is fixed at 1 MB, 2 MB, or 8 MB.
9.2.3 Pre-allocated Memory
Voids of physical addresses that are not accessible as general system memory and reside within
system memory address range (< TOLUD) are created for SMM-mode and legacy VGA graphics
compatibility. It is the responsibility of BIOS to properly initialize these regions. Table 9-4
details the location and attributes of the regions.
Table 9-4. Pre-Allocated Memory Example for 64-MB DRAM and 1-MB TSEG
Memory Segments Attributes Comments
0000_0000h – 03DF_FFFFh R/W Available system memory 62 MB
03E0_0000h – 03EF_FFFFh SMM Mode Only -
processor reads
TSEG Address Range and Pre-allocated
memory
03F0_0000h – 03FF_FFFFh R/W Pre-allocated Graphics VGA memory.
9.3 PCI Memory Address Range (TOLUD – 4 GB)
This address range, from the top of physical memory to 4 GB (top of addressable memory space
supported by the MCH) is normally mapped via the DMI to PCI.
Note: AGIP Aperture no longer exists with PCI Express.
