Testability
R
Intel
®
82925X/82925XE MCH Datasheet 221
13 Testability
In the 82925X/82925XE MCH, testability for Automated Test Equipment (ATE) board level
testing has been implemented as an XOR chain. An XOR-tree is a chain of XOR gates each with
one input pin connected to it.
13.1 Complimentary Pins
Table 13-1 contains pins which must remain complimentary while performing XOR testing. The
first and third columns contain the pin and its compliment. The second and fourth columns
specify which chain the associated pins are on.
Note: In non ECC systems, SDQS_A8, SDQS_A8#, SDQS_B8 and SDQS_B8# do not need to be
driven.
Table 13-1. Complimentary Pins to Drive
Complimentary Pin XOR Chain Complimentary Pin XOR Chain
SDQS_A0 SM XOR 6 SDQS_A0# SM XOR 4
SDQS_A1 SM XOR 6 SDQS_A1# SM XOR 4
SDQS_A2 SM XOR 6 SDQS_A2# SM XOR 4
SDQS_A3 SM XOR 4 SDQS_A3# SM XOR 6
SDQS_A4 SM XOR 4 SDQS_A4# SM XOR 2
SDQS_A5 SM XOR 2 SDQS_A5# SM XOR 4
SDQS_A6 SM XOR 2 SDQS_A6# SM XOR 4
SDQS_A7 SM XOR 2 SDQS_A7# SM XOR 4
SDQS_A8 (82925X)
RSV (82925XE)
SM XOR 2 SDQS_A8# (82925X)
RSV (82925XE)
SM XOR 4
SDQS_B0 SM XOR 7 SDQS_B0# SM XOR 5
SDQS_B1 SM XOR 7 SDQS_B1# SM XOR 5
SDQS_B2 SM XOR 7 SDQS_B2# SM XOR 5
SDQS_B3 SM XOR 7 SDQS_B3# SM XOR 5
SDQS_B4 SM XOR 7 SDQS_B4# SM XOR 5
SDQS_B5 SM XOR 3 SDQS_B5# SM XOR 5
SDQS_B6 SM XOR 3 SDQS_B6# SM XOR 5
SDQS_B7 SM XOR 3 SDQS_B7# SM XOR 5
SDQS_B8 (82925X)
RSV (82925XE)
SM XOR 7 SDQS_B8# (82925X)
RSV (82925XE)
SM XOR 5
