Ballout and Package Information
R
Intel
®
82925X/82925XE MCH Datasheet 219
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
AP13 SMA_B6
AP14 SMA_B3
AP15 SMA_B10
AP16 VCCSM
AP17 SWE_B#
AP18 SCAS_B#
AP19 SCKE_A0
AP20 VCCSM
AP21 SMA_A11
AP22 SMA_A9
AP23 SMA_A4
AP24 VCCSM
AP25 SMA_A1
AP26 SMA_A10
AP27 SRAS_A#
AP28 VCCSM
AP29 SCAS_A#
AP30 SODT_A0
AP31 SCS_A3#
AP32 SODT_A1
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
AP33 SCS_B0#
AP34 SCS_B3#
AP35 NC
AR1 NC
AR2 NC
AR3 VSS
AR4 —
AR5 SDQ_A20
AR6 VSS
AR7 VCCSM
AR8 SCKE_B2
AR9 SCKE_B0
AR10 VCCSM
AR11 SMA_B7
AR12 SMA_B8
AR13 VSS
AR14 VCCSM
AR15 SMA_B1
AR16 SBS_B0
AR17 VSS
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
AR18 VCCSM
AR19 SCKE_A3
AR20 SBS_A2
AR21 VSS
AR22 VCCSM
AR23 SMA_A6
AR24 SMA_A3
AR25 VSS
AR26 VCCSM
AR27 SBS_A1
AR28 SCS_A2#
AR29 SCS_A0#
AR30 VSS
AR31 VCCSM
AR32 —
AR33 VCCSM
AR34 NC
AR35 NC
12.2 Package Information
The MCH package measures 37.5 mm × 37.5 mm. The 1210 balls are located in a non-grid
pattern. For example, the ball pitch varies from 31.8 mils to 43.0 mils, depending on the X-axis or
Y-axis direction. Figure 12-3 shows the physical dimensions of the package.
