Ballout and Package Information
R
218 Intel
®
82925X/82925XE MCH Datasheet
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
AL21
SCB_B6 (82925X)
RSV (82925XE)
AL22
SCB_B7 (82925X)
RSV (82925XE)
AL23 SCLK_B3
AL24 VSS
AL25 SDQ_B38
AL26 SDQ_B34
AL27 NC
AL28 SCLK_A3
AL29 SCLK_A0
AL30 SDQ_A36
AL31 SDQ_A37
AL32 VSS
AL33 SODT_B3
AL34 SODT_B1
AL35 SODT_B2
AM1 —
AM2 SCLK_A4#
AM3 SCLK_A4
AM4 VSS
AM5 SDQS_B1
AM6 VSS
AM7 SDQ_A22
AM8 SDQ_A23
AM9 SDQ_A18
AM10 VCCSM
AM11 VCCSM
AM12 NC
AM13 VCCSM
AM14 VCCSM
AM15 NC
AM16 VCCSM
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
AM17 VCCSM
AM18 NC
AM19 VCCSM
AM20 VCCSM
AM21 NC
AM22 VCCSM
AM23 VCCSM
AM24 NC
AM25 VCCSM
AM26 VCCSM
AM27 VCCSM
AM28 VSS
AM29 VCCSM
AM30 SCLK_A0#
AM31 VSS
AM32 VCCSM
AM33 SCS_B1#
AM34 SMA_B13
AM35 —
AN1 VSS
AN2 SCLK_A1
AN3 SCLK_A1#
AN4 SDQ_A10
AN5 SDQ_A21
AN6 SDQ_B15
AN7 SDQS_A2#
AN8 SCKE_B3
AN9 SBS_B2
AN10 SMA_B12
AN11 SMA_B5
AN12 —
AN13 SMA_B4
AN14 SMA_B2
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
AN15 SMA_B0
AN16 SBS_B1
AN17 SRAS_B#
AN18 SCKE_A2
AN19 SCKE_A1
AN20 SMA_A12
AN21 SMA_A7
AN22 SMA_A5
AN23 SMA_A8
AN24 —
AN25 SMA_A2
AN26 SMA_A0
AN27 SBS_A0
AN28 SWE_A#
AN29 SODT_A2
AN30 SMA_A13
AN31 SCS_A1#
AN32 SODT_A3
AN33 SCS_B2#
AN34 SODT_B0
AN35 VCCSM
AP1 NC
AP2 SDQ_A14
AP3 SDQ_A15
AP4 SDQ_A11
AP5 SDQ_A16
AP6 SDM_A2
AP7 SDQS_A2
AP8 VCCSM
AP9 SCKE_B1
AP10 SMA_B11
AP11 SMA_B9
AP12 VCCSM
