Ballout and Package Information
R
Intel
®
82925X/82925XE MCH Datasheet 217
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
AH35 SDQ_A41
AJ1 SDQ_A12
AJ2 SDQ_A3
AJ3 SDQ_A13
AJ4 VSS
AJ5 SDQ_B13
AJ6 SDQ_B3
AJ7 SDQ_B2
AJ8 SDQ_B6
AJ9 VSS
AJ10 VSS
AJ11 SCLK_B4
AJ12 SM_SLEWIN0
AJ13 VSS
AJ14 NC
AJ15 VSS
AJ16 VSS
AJ17 SDQ_A31
AJ18
SCB_B1 (82925X)
RSV (82925XE)
AJ19 VSS
AJ20
SCB_B0 (82925X)
RSV (82925XE)
AJ21
SDQS_B8# (82925X)
RSV (82925XE)
AJ22 VSS
AJ23
SCB_B2 (82925X)
RSV (82925XE)
AJ24
SCB_B3 (82925X)
RSV (82925XE)
AJ25 SDQ_B39
AJ26 SDQ_B35
AJ27 VSS
AJ28 SDQS_A4#
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
AJ29 SDQ_B44
AJ30 VSS
AJ31 SDQ_B41
AJ32 VSS
AJ33 SDM_A4
AJ34 SDQ_A45
AJ35 VSS
AK1 VSS
AK2 SDQ_A8
AK3 SDQ_A9
AK4 VSS
AK5 SDM_B1
AK6 VSS
AK7 SDQ_A17
AK8 VSS
AK9 SCLK_B1
AK10 SDQ_B8
AK11 VSS
AK12 SM_SLEWOUT0
AK13 SDQ_B22
AK14 VSS
AK15 RSV_TP3
AK16 SDQ_A30
AK17 VSS
AK18
SCB_B5 (82925X)
RSV (82925XE)
AK19 SDQ_B27
AK20 VSS
AK21
SDQS_B8 (82925X)
RSV (82925XE)
AK22 SCLK_B3#
AK23 VSS
AK24 NC
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
AK25 VSS
AK26 VSS
AK27 SDQS_A4
AK28 SCLK_A3#
AK29 SDQ_A32
AK30 VSS
AK31 SDQ_A33
AK32 SDQ_B40
AK33 SDQ_B45
AK34 SDQ_A44
AK35 VCCSM
AL1 SDM_A1
AL2 SDQS_A1#
AL3 SDQS_A1
AL4 SDQ_B9
AL5 SDQS_B1#
AL6 SDQ_B14
AL7 SDQ_A19
AL8 SDQ_B10
AL9 SCLK_B1#
AL10 VSS
AL11 SCLK_B4#
AL12 VCCSM
AL13 VSS
AL14 SDQ_B23
AL15 RSV_TP2
AL16 VSS
AL17 SDQ_A26
AL18 SDQ_B26
AL19 VSS
AL20
SCB_B4 (82925X)
RSV (82925XE)
