Ballout and Package Information
R
216 Intel
®
82925X/82925XE MCH Datasheet
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
AF6 VSS
AF7 RSTIN#
AF8 VSS
AF9 SM_SLEWIN1
AF10 VSS
AF11 SDQ_B5
AF12 SDQ_B11
AF13 SDQ_B16
AF14 SDQ_B18
AF15 SDQ_B28
AF16 SDQ_A25
AF17 SDM_A3
AF18 VSS
AF19 NC
AF20 SDQS_B3#
AF21 VSS
AF22 NC
AF23 SDQ_B36
AF24 SDQ_B32
AF25 SDM_B4
AF26 VSS
AF27 SDQ_B48
AF28 SDQ_A39
AF29 VSS
AF30 SDQ_B43
AF31 VSS
AF32 VSS
AF33 SDQ_A42
AF34 SDQ_A47
AF35 VSS
AG1 SDQS_A0
AG2 SDQS_A0#
AG3 SDQ_A6
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
AG4 SRCOMP0
AG5 VSS
AG6 NC
AG7 PWROK
AG8 SRCOMP1
AG9 VSS
AG10 SDQ_B1
AG11 SDQ_B0
AG12 VSS
AG13 VSS
AG14 SDQS_B2#
AG15 VSS
AG16 VSS
AG17 SDQS_A3#
AG18 VSS
AG19 VSS
AG20 SDQS_B3
AG21 VSS
AG22 VSS
AG23 SCLK_B0#
AG24 SDQ_B33
AG25 NC
AG26 SDQS_B4#
AG27 SDQ_A38
AG28 SDQ_B47
AG29 NC
AG30 SDQ_B46
AG31 SDQ_B42
AG32 SDQ_A46
AG33 SDQS_A5#
AG34 SDM_A5
AG35 SDQS_A5
AH1 VSS
Table 12-2. MCH Ballout
Sorted By Ball Number
Ball # Signal Name
AH2 SDQ_A7
AH3 SDQ_A2
AH4 SDQ_B12
AH5 NC
AH6 VSS
AH7 SDQ_B7
AH8 SDQS_B0
AH9 SDQS_B0#
AH10 SDM_B0
AH11 VSS
AH12 SDM_B2
AH13 SDQS_B2
AH14 VSS
AH15 RSV_TP1
AH16 SDQS_A3
AH17 SDQ_A27
AH18 VSS
AH19 SDQ_B30
AH20 VSS
AH21 SDQ_B31
AH22 VSS
AH23 SCLK_B0
AH24 NC
AH25 SDQS_B4
AH26 VSS
AH27 SDQ_A34
AH28 SDQS_B5
AH29 VSS
AH30 SDQS_B5#
AH31 SDM_B5
AH32 VSS
AH33 VSS
AH34 SDQ_A40
