Ballout and Package Information
R
Intel
®
82925X/82925XE MCH Datasheet 197
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
HA24# P28
HA25# R28
HA26# N33
HA27# T27
HA28# T31
HA29# U28
HA30# T26
HA31# T29
HADS# M31
HADSTB0# J31
HADSTB1# N27
HBNR# M35
HBPRI# E30
HBREQ0# R33
HCLKN M22
HCLKP M23
HCPURST# G24
HD00 J33
HD1 H33
HD2 J34
HD3 G35
HD4 H35
HD5 G34
HD6 F34
HD7 G33
HD8 D34
HD9 C33
HD10 D33
HD11 B34
HD12 C34
HD13 B33
HD14 C32
HD15 B32
HD16 E28
HD17 C30
HD18 D29
HD19 H28
HD20 G29
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
HD21 J27
HD22 F28
HD23 F27
HD24 E27
HD25 E25
HD26 G25
HD27 J25
HD28 K25
HD29 L25
HD30 L23
HD31 K23
HD32 J22
HD33 J24
HD34 K22
HD35 J21
HD36 M21
HD37 H23
HD38 M19
HD39 K21
HD40 H20
HD41 H19
HD42 M18
HD43 K18
HD44 K17
HD45 G18
HD46 H18
HD47 F17
HD48 A25
HD49 C27
HD50 C31
HD51 B30
HD52 B31
HD53 A31
HD54 B27
HD55 A29
HD56 C28
HD57 A28
HD58 C25
Table 12-1. MCH Ballout
Sorted By Signal Name
Signal Name Ball #
HD59 C26
HD60 D27
HD61 A27
HD62 E24
HD63 B25
HDBSY# L35
HDEFER# J35
HDINV0# E34
HDINV1# J26
HDINV2# K19
HDINV3# B26
HDRDY# M32
HDSTBN0# E35
HDSTBN1# F26
HDSTBN2# F19
HDSTBN3# C29
HDSTBP0# E33
HDSTBP1# H26
HDSTBP2# J19
HDSTBP3# B29
HEDRDY# P33
HHIT# L34
HHITM# N35
HLOCK# L33
HPCREQ# E31
HRCOMP B23
HREQ0# F33
HREQ1# E32
HREQ2# H31
HREQ3# G31
HREQ4# F31
HRS0# K34
HRS1# P34
HRS2# J32
HSCOMP D24
HSWING A23
HTRDY# N34
HVREF A24
