Testability
R
224 Intel
®
82925X/82925XE MCH Datasheet
Chain Pin Count Ball Number Signal Name
0 34 H28 HD19
0 35 F27 HD23
0 36 F28 HD22
0 37 H26 HDSTBP1#
0 38 F26 HDSTBN1#
0 39 J27 HD21
0 40 J25 HD27
0 41 K25 HD28
0 42 K23 HD31
0 43 L23 HD30
0 44 J26 HDINV1#
0 45 G25 HD26
0 46 L25 HD29
0 47 B32 HD15
0 48 G33 HD7
0 49 H33 HD1
0 50 H35 HD4
0 51 J34 HD2
0 52 G30 HA6#
0 53 H29 HA3#
0 54 J28 HA13#
0 55 J29 HA5#
0 56 K33 HA15#
0 57 F31 HREQ4#
0 58 K29 HA4#
0 59 L31 HA11#
0 60 K27 HA14#
0 61 M30 HA10#
0 62 F33 HREQ0#
0 63 E30 HBPRI#
0 64 J35 HDEFER#
0 65 P33 HEDRDY#
XOR Chain #0 Output D17 BSEL2
