Figure 4-5-3: Aggregation Group Configuration page screenshot
The page includes the following fields:
.Object Description
• Group ID
Indicates the group ID for the settings contained in the same row.
Group ID "Normal" indicates there is no aggregation. Only one
group ID is valid per port.
• Port Members
Each switch port is listed for each group ID. Select a radio button
to include a port in an aggregation, or clear the radio button to
remove the port from the aggregation. By default, no ports
belong to any aggregation group.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
