: Clears all Statistics counters.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
4.8.12 MLD Group Information
Entries in the MLD Group Table are shown on this page. The MLD Group Table is sorted first by VLAN
ID, and then by group.
Each page shows up to 99 entries from the MLD Group table, default being 20, selected through the
"entries per page" input field. When first visited, the web page will show the first 20 entries from the
beginning of the MLD Group Table.
The "Start from VLAN", and "group" input fields allow the user to select the starting point in the MLD
Group Table.
The MLD Groups Information screen in Figure 4-8-15 appears.
Figure 4-8-15: MLD Snooping Groups Information page screenshot
The page includes the following fields:
Object Description
• VLAN ID
VLAN ID of the group.
• Groups
Group address of the group displayed.
• Port Members
Ports under this group.
Buttons
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
: Click to refresh the page immediately.
: Updates the table, starting with the first entry in the IGMP Group Table.
: Updates the table, starting with the entry after the last entry currently displayed.
To Next Page
