1.5 Product Specification
Product NS3502-8P-2S
Hardware Specification
Copper Ports 8 10/ 100/1000Base-T RJ-45 Auto-MDI/MDI-X ports
SFP/mini-GBIC Slots
2 1000Base-SX/LX/BX SFP interfaces (Port-9 and Port-10)
Compatible with 100Base-FX SFP
Console Port 1 x RS-232 DB9 serial port (115200, 8, N, 1)
Switch Architecture Store-and-Forward
Switch Fabric 20Gbps / non-blocking
Address Table 8K entries, automatic source address learning and ageing
Share data Buffer 1392 kilobytes
Flow Control
IEEE 802.3x Pause Frame for Full-Duplex
Back pressure for Half-Duplex
Jumbo Frame 9Kbytes
Reset Button
< 5 seconds: System reboot
> 10 seconds: Factory Default
Dimension (W x D x H) 330 x 155 x 43.5 mm, 1U high
Weight
1.8kg
LED
Power, FAN Alert,
Link/Act per Gigabit port,
PoE In-Use for port-1~ 8
Power Consumption
Max. 172.9 watts /
589.6 BTU
Power Requirement – AC
AC 100~240V, 50/60Hz
Operating Temperature
0 to 50®C (32 to 122®F)
Limited Warranty
3 Years
Power over Ethernet
PoE Standard
IEEE 802.3af / at PoE / PSE
PoE Power Supply Type
End-Span
PoE Power Output
Per Port 56V DC.
Max. 30.8 watts
Power Pin Assignment
1/2(+), 3/6(-)
PoE Power Budget
150 Watts
PoE Ability
Number of PD
@ 7Watts
8
Number of PD
@ 15.4Watts
8
Number of PD
@ 30.8Watts
4
