whole aggregation will act as a router port.
• Fast Leave
Enable the fast leave on the port.
• Throtting
Enable to limit the number of multicast groups to which a switch
port can belong.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.8.3 IGMP Snooping VLAN Configuration
Each page shows up to 99 entries from the VLAN table, default being 20, selected through the "entries
per page" input field. When first visited, the web page will show the first 20 entries from the beginning
of the VLAN Table. The first displayed will be the one with the lowest VLAN ID found in the VLAN Table.
The "VLAN" input fields allow the user to select the starting point in the VLAN Table. The IGMP
Snooping VLAN Configuration screen in Figure 4-8-6 appears.
Figure 4-8-6: IGMP Snooping VLAN Configuration page screenshot
The page includes the following fields:
Object Description
• VLAN ID
The VLAN ID of the entry.
• IGMP Snooping
Enable
Enable the per-VLAN IGMP Snooping. Only up to 64 VLANs can be
selected.
• IGMP Querier
Enable the IGMP Querier in the VLAN.
• RV
Robustness Variable. The Robustness Variable allows tuning for
the expected packet loss on a network. The allowed range is 1 to
