Buttons
: Click to refresh the page immediately.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
4.5.5 LACP Port Statistics
This page provides an overview for LACP statistics for all ports. The LACP Port Statistics screen in Figure
4-5-7 appears.
Figure 4-5-7: LACP Statistics page screenshot
The page includes the following fields:
Object Description
• Port
The switch port number.
• LACP Received
Shows how many LACP frames have been sent from each port.
• LACP Transmitted
Shows how many LACP frames have been received at each port.
• Discarded
Shows how many unknown or illegal LACP frames have been
discarded at each port.
Buttons
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
: Click to refresh the page immediately.
: Clears the counters for all ports.
