4.7.5 MSTI Priorities
This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and
possibly change them as well. The MSTI Priority screen in Figure 4-7-10 appears.
Figure 4-7-10: MSTI Priority page screenshot
The page includes the following fields:
Object Description
• MSTI
The bridge instance. The CIST is the default instance, which is
always active.
• Priority
Controls the bridge priority. Lower numerical values have better
priority. The bridge priority plus the MSTI instance number,
concatenated with the 6-byte MAC address of the switch forms a
Bridge Identifier.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
