• Immediate Leave
Enable the fast leave on the port.
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.8.15 MVR Status
This page provides MVR status. The MVR Status screen in Figure 4-8-18 appears.
Figure 4-8-18: MVR Status page screenshot
The page includes the following fields:
Object Description
• Group
The Multicast VLAN ID.
• V1 Reports
Received
The number of Received V1 Reports.
• V2 Reports
Received
The number of Received V2 Reports.
• V3 Reports
Received
The number of Received V3 Reports.
• V2 Leave Received
The number of Received V2 Leaves.
Buttons
: Click to refresh the page immediately.
: Clears all Statistics counters.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
