• Priority
The Priority shows the port's priority configured by the user.
• Port Status
The Port Status shows the port's status.
• Total
Show the total watts usage of all PDs.
Buttons
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
: Click to refresh the page immediately.
4.16.5 PoE Schedule
This page allows the user to define PoE schedule. The screen in Figure 4-16-5 appears.
Figure 4-16-5: PoE Schedule screenshot
Please press Add New Rule button to start set PoE Schedule function. You have to set PoE schedule to
profile then go back to PoE Port Configuration, and select “Schedule” mode from per port “PoE Mode”
option then you can indicate which schedule profile could be apply to the PoE port.
