Object Description
• DSCP
Maximum number of supported DSCP values is 64.
• Trust
Click to check if the DSCP value is trusted.
• QoS Class
QoS Class value can be any of (0-7)
• DPL
Drop Precedence Level (0-1)
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.9.9 DSCP Translation
This page allows you to configure the basic QoS DSCP Translation settings for all switches. DSCP
translation can be done in Ingress or Egress. The DSCP Translation screen in Figure 4-9-11 appears.
