458
STP Port RestrictedRole
Description:
Set or show the MSTP restrictedRole port parameter.
Syntax:
STP Port RestrictedRole [<port_list>] [enable|disable]
Parameters:
<port_list>: Port list or 'all', default: All ports
enable : Enable MSTP restricted role
disable : Disable MSTP restricted role
Default:
Disable
Example:
Enable STP restricted role on port1
NS3502
-8P-2S:/>stp port restrictedrole 1 enable
STP Port RestrictedTcn
Description:
Set or show the MSTP restrictedTcn port parameter.
Syntax:
STP Port RestrictedTcn [<port_list>] [enable|disable]
Parameters:
<port_list>: Port list or 'all', default: All ports
enable : Enable MSTP restricted TCN
disable : Disable MSTP restricted TCN
Default:
Disable
Example:
Eisable STP restricted TCN on port1
NS3502
-8P-2S:/>stp port restrictedtcn 1 enable
