4.3.4 SNMPv3 Configuration
4.3.4.1 SNMPv3 Communities
Configure SNMPv3 communities table on this page. The entry index key is Community. The SNMPv3
Communities screen in Figure 4-3-4 appears.
Figure 4-3-4: SNMPv3 Communities Configuration page screenshot
The page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• Community
Indicates the community access string to permit access to
SNMPv3 agent. The allowed string length is 1 to 32, and the
allowed content is the ASCII characters from 33 to 126.
• Source IP
Indicates the SNMP access source address.
• Source Mask
Indicates the SNMP access source address mask.
Buttons
: Click to add a new community entry.
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
