Interlogix IFS NS3502-8P-2S User Manual

IFS NS3502-8P-2S User Manual
76
4.2.19 TFTP Firmware Upgrade
The Firmware Upgrade page provides the functions to allow a user to update the Managed Switch
firmware from the TFTP server in the network. Before updating, make sure you have your TFTP server
ready and the firmware image is on the TFTP server. The TFTP Firmware Upgrade screen in Figure
4-2-23 appears.
Figure 4-2-23: TFTP Firmware Update page screenshot
The page includes the following fields:
Object Description
• TFTP Server IP
Fill in your TFTP server IP address.
• Firmware File
Name
The name of firmware image.
(Maximum length : 24 characters)
Buttons
: Click to upgrade firmware.
DO NOT Power OFF the Managed Switch until the update progress is
complete.
Do not quit the Firmware Upgrade page without press the “OK” button -
after the image is loaded. Or the system won’t apply the new firmware.
User has to repeat the firmware upgrade processes again.
4.2.20 Configuration Backup
This function allows backup and reload the current configuration of the Managed Switch to the local
management station. The Configuration Backup screen in Figure 4-2-24 appears.
