• Address
Provide the IPv6 address of this switch. IPv6 address is in 128-bit records
represented as eight fields of up to four hexadecimal digits with a colon
separate each field (:). For example, ‘fae0::013:4fefe:dea4:34d4’
. The symbol '::' is a special syntax that can be used as a shorthand way of
representing multiple 16-bit groups of contiguous zeros; but it can only
appear once. It also used a following legally IPv4 address. For example, '::
192.1.2.34’.
• Prefix
Provide the IPv6 Prefix of this switch. The allowed range is 1 through 128.
• Router
Provide the IPv6 gateway address of this switch. IPv6 address is in 128-bit
records represented as eight fields of up to four hexadecimal digits with a
colon separate each field (:). For example, ‘fae0::013:4fefe:dea4:34d4’. The
symbol '::' is a special syntax that can be used as a shorthand way of
representing multiple 16-bit groups of contiguous zeros; but it can only
appear once. It also used a following legally IPv4 address. For example,
'::192.1.2.34'.
Provide the IPv6 SNTP Server address of this switch. IPv6 address is in
128-bit records represented as eight fields of up to four hexadecimal digits
with a colon separate each field (:). For example,
'fae0::013:4fefe:dea4:34d4’. The symbol '::' is a special syntax that can be
used as a shorthand way of representing multiple 16-bit groups of
contiguous zeros; but it can only appear once. It also used a following
legally IPv4 address. For example, '::192.1.2.34'.
• VLAN ID
Provide the managed VLAN ID. The allowed range is 1 through 4095
Buttons
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.2.4 Users Configuration
This page provides an overview of the current users. Currently the only way to login as another user on
the web server is to close and reopen the browser. After setup completed, please press “Save” button
to take effect. Please login web interface with new user name and password, the screen in Figure 4-2-4
appears.
