Interlogix IFS NS3502-8P-2S User Manual

IFS NS3502-8P-2S User Manual
329
The PD is classified based on power. The classification of the PD is the maximum power that the PD will
draw across all input voltages and operational modes.
A PD shall return Class 0 to 4 in accordance with the maximum power draw as specified by Table
4-16-1.
Class Usage
Range of maximum power used by
the PD
Class Description
0 Default 0.44 to 12.95 Watts
Classification
unimplemented
1
Optional
0.44 to 3.84 Watts
Very low power
2
Optional
3.84 to 6.49 Watts
Low power
3
Optional
6.49 to 12.95 Watts (or to 15.4Watts)
Mid power
4 Optional
12.95 to 25.50 Watts (or to
30.8Watts)
High power
Table 4-16-1: Device class
4.16.3 Port Configuration
This section allows the user to inspect and configure the current PoE port settings; screen in Figure 4-16-3 appears.
Figure 4-16-3: Power over Ethernet Configuration screenshot
The page includes the following fields:
Object Description
• PoE Mode
There are three modes for PoE mode.
Enable: enable PoE function...
Disable: disable PoE function.
Schedule: enable PoE function in schedule mode.
• Schedule
Indicates the schedule profile mode. Possible porifles are:
Profile1
Profile2
Profile3
