packet's behavior at the egress side.
• Conflicts
Shows status of Conflicts whether exists or Not. When a Volatile
VLAN User requests to set VLAN membership or VLAN port
configuration, the following conflicts can occur:
Functional Conflicts between features.
Conflicts due to hardware limitation.
Direct conflict between user modules.
• VLAN User
A VLAN User is a module that uses services of the VLAN
management functionality to configure VLAN memberships and
VLAN port configuration such as PVID, UVID. Currently we
support following VLAN :
- CLI/Web/SNMP : This is referred as static.
- NAS : NAS provides port-based authentication, which involves
communications between a Supplicant, Authenticator, and an
Authentication Server.
- Voice VLAN : Voice VLAN is a VLAN configured specially for
voice traffic typically originating from IP phones.
- MVR : MVR is used to eliminate the need to duplicate
multicast traffic for subscribers in each VLAN. Multicast traffic
for all channels is sent only on a single (multicast) VLAN.
- MSTP : The 802.1s Multiple Spanning Tree protocol (MSTP)
uses VLANs to create multiple spanning trees in a network,
which significantly improves network resource utilization
while maintaining a loop-free environment.
Buttons
: Select VLAN Users from this drop down list.
Auto-refresh : Check this box to enable an automatic refresh of the page at regular intervals.
: Click to refresh the page immediately.
4.6.8 Private VLAN
The Private VLAN membership configurations for the switch can be monitored and modified here.
Private VLANs can be added or deleted here. Port members of each Private VLAN can be added or
removed here.
