: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.11.7 RADIUS Overview
This page provides an overview of the status of the RADIUS servers configurable on the
Authentication configuration page. The RADIUS Authentication/Accounting Server Overview
screen in Figure 4-11-8 appears.
Figure 4-11-8: RADIUS Authentication/Accounting Server Overview page screenshot
The page includes the following fields:
RADIUS Authentication Servers
Object Description
• #
The RADIUS server number. Click to navigate to detailed statistics
for this server.
• IP Address
The IP address and UDP port number (in <IP Address> :< UDP
Port> notation) of this server.
• State
The current state of the server. This field takes one of the
following values:
