Figure 4-9-19: Voice VLAN OUI Table page screenshot
The page includes the following fields:
Object Description
• Delete
Check to delete the entry. It will be deleted during the next save.
• Telephony OUI
A telephony OUI address is a globally unique identifier assigned
to a vendor by IEEE. It must be 6 characters long and the input
format is "xx-xx-xx" (x is a hexadecimal digit).
• Description
The description of OUI address. Normally, it descripts which
vendor telephony device. The allowed string length is 0 to 32.
Buttons
: Click to add a new access management entry.
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.10 Access Control Lists
ACL is an acronym for Access Control List. It is the list table of ACEs, containing access control entries
that specify individual users or groups permitted or denied to specific traffic objects, such as a process
or a program.
