4.11.8 RADIUS Details
This page provides detailed statistics for a particular RADIUS server. The RADIUS
Authentication/Accounting for Server Overview screen in Figure 4-11-9 appears.
Figure 4-11-9: RADIUS Authentication/Accounting for Server Overview page screenshot
The page includes the following fields:
RADIUS Authentication Servers
The statistics map closely to those specified in RFC4668 - RADIUS Authentication Client MIB.
Use the server select box to switch between the backend servers to show details for.
Object Description
• Packet Counters
RADIUS authentication server packet counter. There are seven receive
and four transmit counters.
