application type. L2 Priority may specify one of eight priority
levels (0 through 7), as defined by IEEE 802.1D-2004. A value of 0
represents use of the default priority as defined in IEEE
802.1D-2004.
• DSCP
DSCP value to be used to provide Diffserv node behavior for the
specified application type as defined in IETF RFC 2474. DSCP may
contain one of 64 code point values (0 through 63). A value of 0
represents use of the default DSCP value as defined in RFC 2475.
Port Policies Configuration
Every port may advertise a unique set of network policies or different attributes for the same network
policies, based on the authenticated user identity or port configuration.
Object Description
• Port
The port number for which the configuration applies.
• Policy ID
The set of policies that shall apply for a given port. The set of
policies is selected by check marking the checkboxes that
corresponds to the policies
Buttons
: click to add new policy.
: Click to save changes.
: Click to undo any changes made locally and revert to previously saved values.
4.14.4 LLDP-MED Neighbor
This page provides a status overview for all LLDP-MED neighbors. The displayed table contains a row
for each port on which an LLDP neighbor is detected. The LLDP-MED Neighbor Information screen in
Figure 4-14-3 appears. The columns hold the following information:
