Example:
Delete 00-11-22-33-44-55-66 in MAC-based VLAN list
NS3502
-8P-2S:/> vcl macvlan del 00-11-22-33-44-55-66
VCL Status
Description:
Show VCL MAC-based VLAN users configuration.
Syntax:
VCL Status [combined|static|nas|all]
Parameters:
combined|static|nas|all: VCL User
VCL Protocol-based VLAN Add Ethernet II
Description:
Add VCL protocol-based VLAN Ethernet-II protocol to group mapping.
Syntax:
VCL ProtoVlan Protocol Add Eth2 <ether_type>|arp|ip|ipx|at <group_id>
Parameters:
<ether_type>|arp|ip|ipx|at: Ether Type (0x0600 - 0xFFFF)
<group_id> : Protocol group ID
VCL Protocol-based VLAN Add SNAP
Description:
Add VCL protocol-based VLAN SNAP protocol to group mapping.
Syntax:
VCL ProtoVlan Protocol Add Snap <oui>|rfc_1042|snap_8021h <pid> <group_id>
Parameters:
<oui>|rfc_1042|snap_8021h: OUI value (Hexadecimal 00-00-00 to FF-FF-FF).
