IFS NS3502-8P-2S User Manual
Disabled: Frames matching the ACE are not logged.
Please note that the System Log memory size and logging rate is
limited.
• Shutdown
Indicates the port shut down operation of the ACE. Possible
values are:
Enabled: If a frame matches the ACE, the ingress port will be
disabled.
Disabled: Port shut down is disabled for the ACE.
• Counter
The counter indicates the number of times the ACE was hit by a
frame.
• Modification
Buttons
You can modify each ACE (Access Control Entry) in the table using
the following buttons:
: Inserts a new ACE before the current row.
: Edits the ACE row.
: Moves the ACE up the list.
: Moves the ACE down the list.
: Deletes the ACE.
: The lowest plus sign adds a new entry at the bottom of the
Buttons
Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs at regular
intervals.
: Click to refresh the page; any changes made locally will be undone.
: Click to clear the counters.
: Click to remove all ACEs.
4.10.3 ACE Configuration
Configure an ACE (Access Control Entry) on this page.
An ACE consists of several parameters. These parameters vary according to the frame type that
you select. First select the ingress port for the ACE, and then select the frame type. Different
parameter options are displayed depending on the frame type selected.
A frame that hits this ACE matches the configuration that is defined here. The ACE Configuration
screen in Figure 4-10-3 appears.
