4.14.6 Port Statistics
This page provides an overview of all LLDP traffic. Two types of counters are shown. Global counters
are counters that refer to the whole stack, switch, while local counters refer to counters for the
currently selected switch. The LLDP Statistics screen in Figure 4-14-5 appears.
Figure 4-14-5: LLDP Statistics page screenshot
The page includes the following fields:
Global Counters
Object Description
• Neighbor entries
were last changed
on
It also shows the time when the last entry was last deleted or
added. It also shows the time elapsed since the last change was
detected.
• Total Neighbors
Entries Added
Shows the number of new entries added since switch reboot.
• Total Neighbors
Entries Deleted
Shows the number of new entries deleted since switch reboot.
• Total Neighbors
Entries Dropped
Shows the number of LLDP frames dropped due to that the entry
table was full.
• Total Neighbors
Entries Aged Out
Shows the number of entries deleted due to Time-To-Live
expiring.
Local Counters
The displayed table contains a row for each port. The columns hold the following information:
